Reliable EV Charger PCBA Supplier Customizable PCBA Solutions For Bus Automatic Chargers

1. EV Charging Pile PCBA Product Features
(1) High Reliability
Designed for 10+ years of continuous operation; anti-vibration & EMI-resistant.
(2) High-Efficiency Power Conversion
Conversion efficiency ≥95% (reduces energy loss & heat generation).
3. Comprehensive Safety Protections
Over-voltage/current/heat, short-circuit & leakage protection (complies with IEC 61851, GB/T standards).
4. Global Compatibility
Supports CCS, CHAdeMO, GB/T, Type 2 charging protocols for universal EV models.
5. Intelligent Management
Integrated MCU for real-time monitoring, 4G/5G/WiFi communication & cloud-based remote control.
6. Optimized Thermal Design
Heat sink & thermal paste for stable operation under high loads.
7. Harsh Environment Adaptability
IP65/IP67 protection (optional), -30°C to +70°C operating range, dust/waterproof.

Electric Vehicle Charging Pile PCBA Technical Information

1. Process Flow

2. Product Features

3. Common Parameters

3.Common technical parameters of EV Charger PCBA

common technical parameters for EV Charger PCBA, tailored for an in-house factory offering customization services:

Customization Services Include:

• Material Selection: Customizable substrates (e.g., ceramic for extreme environments)
• Layer Configuration: Tailored stack-ups for high-speed signal integrity
• Functional Modules: Integration of RFID, NFC, LCD displays, or OCPP 1.6J communication
• Environmental Testing: Customized thermal cycling, humidity, or vibration protocols
• Compliance: Localized certifications ( eg, ISO9001, IATF16949 ,RoHS compliance)

Our vertically integrated factory ensures full control over design, prototyping, and mass production, with lead times optimized for urgent projects. Contact us for tailored solutions!

4. EV Charger PCBA (Printed Circuit Board Assembly) is mainly applied in the following fields:

- Electric Vehicle Charging Stations: For both AC charging stations (slow charging) and DC fast charging stations, to realize power conversion, control charging processes, and manage communication functions.
- Portable EV Chargers: Used in compact, plug-and-play charging devices for home or on-the-go charging.
- Home Charging Systems: Integrated into wall-mounted home chargers for convenient charging at residential locations.
- Commercial Charging Solutions: Applied in public parking lots, malls, and other commercial venues for mass charging services.
- Industrial Charging Infrastructure: Used in fleet charging stations for logistics companies, public transportation, etc.

These applications focus on power management, safety control, data communication, and charging efficiency optimization for EVs.
